Product number:

LDCURV500TS

Product type:

PA Complete Systems, Installation Loudspeakers, PA Complete Systems Accessories

Type:

Smartlink® Adapter, Array Satellites

Midrange size:

1 x 4", 2 x 4"

System output (RMS)::

1000W

Colour:

Black, Black

Tweeter dimensions:

3 x 1", 6 x 1"

Load rating (RMS):

40W, 80W

Peak power:

80W, 160W, Subwoofer: 1400 W , Array Satellites: 600W

Number of array satellites:

4

Dispersion:

110° horizontal, vertical (each satellite) 5°, 110° horizontal, vertical (each satellite) 10°

Number of Smartlink adapters:

1

Impedance:

16Ohm(s), 8Ohm(s)

Number of subwoofers:

1

Material:

die-cast aluminium

Surface:

powder coated

Max. SPL (continuous):

125dB

Connectors:

1x Speakon compatible, 1x Phoenix

Max. SPL (peak):

131dB

Width:

122mm

Frequency response:

40 - 20000Hz

Dispersion (H x V):

110° horizontal, vertical 30°

Height:

240mm, 122mm

RMS:

Subwoofer: 700 W , Array Satellites: 300W

Depth:

126mm, 57mm, 122mm

Weight:

48,2kg, 3,3kg, 3,44kg, 0,35kg

Amplifier:

Class D

Features:

SmartLink® System, 2x M6 thread for optional wall mount, metal grille, M3 thread for safety rope for installations, internal crossover, 2 x 16 mm flanges, WaveAhead® Technology

Protection circuits:

DSP-based multiband limiter, thermal overload, short circuit, overload

Accessories (included):

Distance bar, Power cord, Speaker cable CURV 500 CABLE 1 (2.2 m)

Subwoofer

Low/mid driver dimensions:

15"

Low/mid driver dimensions (mm):

381mm

Cabinet construction:

vented

Housing material:

plywood

Cabinet surface:

Polyurea

Dimensions Subwoofer (W x H x D):

600 x 437 x587mm

Subwoofer weight:

35.5kg

Subwoofer features:

speakON output, 6 System DSP Presets, Threaded flange M20, 4 ergonomic handels, Powercon
