LOA LD SYSTEMS STINGER 12AG3

Product number:

LDEB122AG3

Product type:

PA loudspeaker

Type:

active

Low/mid driver dimensions:

12"

Low/mid driver dimensions (mm):

304.8mm

Woofer magnet:

Ferrite

Woofer brand:

Custom-made

Woofer voice coil:

2.5"

Woofer voice coil (mm):

63.5mm

Horn:

CD horn

HF driver dimensions:

1"

HF driver dimensions (mm):

25.4mm

HF driver magnet:

Ferrite

HF driver brand:

BMS

HF driver voice coil:

1"

HF driver voice coil (mm):

25.4mm

Amplifier:

Class D

Dispersion (H x V):

90 x 50°

RMS:

500W

Peak power:

1000W

Frequency response:

58 - 20000Hz

Max. SPL (peak):

131dB

Protection circuits:

over voltage, over-current, Multiband limiter, thermal overload

Input sensitivity:

-5dBu

Controls:

2 x gain, mode, 2 x Mic/Line

Indicators:

limit, Mic, mode, on, protect (protection circuit engaged), signal

Line inputs:

2

Line input connectors:

6.3 mm Jack, XLR

Line outputs:

1

Line output connectors:

XLR

Operating voltage:

100 - 120 V / 50 - 60 Hz or 200 - 240 V / 50 - 60 Hz (automatic switching)

Operating Temperature:

0 - 40°C

Relative humidity:

< 80% (non-condensing)

Cabinet material:

15 mm Plywood

Cabinet surface:

Polyurea

Cabinet construction:

vented

Monitor angle:

54°

Width:

390mm

Height:

627mm

Depth:

377mm

Weight:

19.4kg
