LOA LD SYSTEMS GT 12A

Product number:

LDGT12A

Product type:

PA loudspeaker

Type:

Actives

Low/mid driver dimensions:

12"

Woofer size:

304.8mm

Woofer magnet:

Ferrite

Woofer brand:

Custom-made

Woofer voice coil:

2.5"

Woofer voice coil (mm):

63.5mm

Horn:

CD horn

HF driver dimensions:

1"

HF driver dimensions (mm):

25.4mm

HF driver magnet:

Ferrite

HF driver brand:

Celestion

HF driver voice coil:

1"

HF driver voice coil (mm):

25.4mm

Amplifier:

Class D

Dispersion (H x V):

90 x 60°

RMS:

250W

Peak power:

1000W

Frequency response:

60 - 19000Hz

Crossover frequency:

2200Hz

Max. SPL (continuous):

119dB

Max. SPL (peak):

122dB

Protection circuits:

over voltage, HF Driver, over-current

Input sensitivity:

Mic: 150 mV / Line: -10dBu

Controls:

volume, Power, Bass, Mic Gain, Treble, Line Gain

Indicators:

Signal, Limit, Power, Protect (protection circuit engaged)

Line inputs:

1

Line input connectors:

XLR, 6.3 mm jack

Mic inputs:

1, 6.3 mm jack, XLR

Line outputs:

1

Line output connectors:

XLR

Operating voltage:

Switching power supply, 110 V AC - 120 V AC, 220 V AC - 240 V AC (Auto), 50 - 60 Hz

Cabinet material:

15 mm MDF

Cabinet surface:

Dura-vinyl textured paint

Cabinet construction:

vented

Monitor angle:

54°

Width:

389mm

Height:

565mm

Depth:

368mm

Features:

rugged steel grille, dual-tilt flange (0°/5°)

Weight:

20.7kg
